Manufacturer code: 10061169

The MSW profile bender allows you to shape sheet metal in workshops, factories, construction companies and in your private garage. Rollers with a diameter of 32 mm ensure precision operation. The maximum rolling diameter of a round profile is 6.5 mm and the dimensions of a flat profile are 25 x 5 mm. The machine makes it possible to obtain uniform ring-shaped parts with a diameter of min. 770 mm and max 1400 mm. The bending machine is made of durable steel. Mounting holes allow you to attach it to the work surface. The 330 mm long ergonomic hand lever with non-slip grip provides simple and comfortable operation.

Product features:

• - 32 mm (1-17/64 inch) diameter rollers,
• - Rolling of round profiles - max diameter 6.5 mm (1/4 inch),
• - Rolling of flat profiles - 25 x 5 mm (63/64 inches),
• - Ergonomic handle with a length of 330 mm,
• - Made of solid steel.

• - Part number - 10061169
• - Article condition - New
• - Model - MSW-SRM-32
• - Material - Steel
• - Steel flat bar [mm] - 25 x 5
• - Bending angle [°] - 0-360
• - Cable diameter [mm] - 32
• - Material thickness [mm] - 8
• - Minimum rolling diameter [mm] - 770
• - Dimensions (DxSxW) [cm] - 33 x 23 x 50
• - Weight [kg] - 5.5
• - Shipping dimensions (DxSxW) [cm] - 36 x 20 x 21
• - Shipping weight [kg] - 6.3

• - Profile bender
• - Lever
• - Operating instructions
